WELDCLASS Weldforce 210MST MIG Stick TIG Welder + Torch + Regulator WC-210MST. Made in Italy to Weldclass specifications, in one of Europe’s largest & most experienced welding machine manufacturing plants. An Impressive MIG Output Of Up To 210 Amps For Welding Up To 10mm Steel. Very compact and portable weighs 10kg.
| WHAT YOU GET: |
|---|
|
1 x WELDCLASS Weldforce 210MST Welder, WC-210MST |
| 1 x MIG Torch H/Duty BZL 25 4m (made in Europe) |
| 1 x Gas Regulator (made in Europe) |
| 1 x Earth Lead 3m |
| 1 x Driver Roller for 0.6/0.8/0.9mm steel/solid wire |
| 1 x Driver Roller for 0.8/0.9/1.2mm gasless wire |
| FEATURES |
|---|
|
Made in Italy to Weldclass specifications, in one of Europe’s largest & most experienced welding machine manufacturing plants.
|
|
An Impressive MIG Output Of Up To 210 Amps For Welding Up To 10mm Steel.
|
|
Dual Input Modes to allow use with either 10A plug (fitted) or 15A plug (optional)*.
|
|
LCD display – Interactive & easy to use.
|
|
Manual or Synergic MIG controls (enter wire type/size & material thickness and the machine will set parameters automatically).
|
|
26+ MIG Programs – for welding with different wires & materials.
|
|
Very compact and portable weighs 10kg.
|
|
Takes 1kg (D100mm) or 5kg (D200mm) spools.
|
|
Generator Compatible – min 7kva, ideal 10+kva.
|
|
RD function for safe & compliant Stick/MMA welding.
|
|
MIG Adjustments include: Inductance, Soft Start, Burnback, Post-Gas Time, 2T/4T Trigger, Spot Weld Time.
|
|
Stick/MMA Adjustments include: Hot-Start %, Arc-Force %.
|
|
Functions:
– Manual MIG (Gas / Gasless) – Voltage and wire-speed adjusted manually.
– Synergic MIG (Gas / Gasless) – Set wire type/size & material thickness and the machine will set parameters automatically. – Stick / MMA. – TIG (Lift-Arc). |
|
Applications:
– MIG welding <210A in 15A mode, or <170A in 10A mode, with solid mild steel (0.6-1.0mm), gasless flux-cored (0.8-1.2mm), stainless-steel (0.8-1.0mm), aluminium (0.8-1.0mm), & bronze/brazing (0.8-1.0mm) wires.
– Stick/MMA welding <150A in 15A mode, or <130A in 10A mode, with most types of common electrodes (2.0-3.2mm), including steel, stainless-steel, hardfacing & more.
– TIG welding (DC lift-arc) <150A in 15A mode, or <130A in 10A mode, of steel, stainless, copper & chrome molly up to 3mm max thickness (NOT suitable for TIG welding of aluminium – this requires AC/DC TIG capability, such as the Weldforce 202T).
|
