• Brand: UNIMIG
• SKU: U11238
• Primary Input Voltage: 240V Single Phase 50/60Hz
• Supply Plug: 15A
• Ieff (A): 15.0
• Imax (A): 34.0
• Rated Output: 20-250A
• No Load Voltage (V): 92.0
• Protection Class: IP21S
• Insulation Class: H
• Minimum Generator (kVA): 12.0
• Dinse Connector: 35/50
• Standard: AS 60974.1
• Welds: MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze | MMA: Mild Steel, Stainless Steel, Cast Iron | TIG: Mild Steel, Stainless Steel, Aluminium, Copper, Silicon Bronze
• MIG Specifications
• MIG Welding Current Range: 20-250A
• MIG Duty Cycle @ 40°C: 20% @ 250A, 60% @ 144A, 100% @ 112A
• MIG Wire Size Range: 0.6-1.2mm
• MIG Wire Spool Size: 5kg (200mm) / 15kg (300mm)
• MIG Welding Thickness Range: 1-12mm
• Drive Roller Size: 30/22
• TIG Specifications
• TIG Function Type: AC/DC HF TIG & AC/DC Pulse
• TIG Welding Current Range: 3-250A
• TIG Duty Cycle @ 40°C: 30% @ 250A, 60% @ 177A, 100% @ 137A
• TIG Welding Thickness Range: 1-10mm
• MMA Specifications
• STICK Welding Current Range: 10-230A
• STICK Duty Cycle @ 40°C: 20% @ 230A, 60% @ 133A, 100% @ 103A
• STICK Electrode Range: 2.5-4.0mm
• STICK Welding Thickness Range: 2-12mm
• Size & Weight
• Dimensions (mm): 810mm x 280mm x 520mm
• Weight (kg): 34.5kg
• Warranty: 5 Year Warranty as Covered by Unimig

Features:

• Single pulse MIG programs & high-frequency DC TIG
• MIG Smart-Set weld modes for complete synergic setups
• 10 amp plug, so you can use it with any domestic outlet
• 3-in-1 multi-process machine so you can MIG, TIG & STICK
• Spool gun ready for aluminium welding
