• Brand: UNIMIG
• Part Number: U11021
• Primary Input Voltage: 415V Three-Phase
• Supply Plug Unplugged: (32A Recommended)
• Open Circuit Voltage – OCV (V): 71.0
• Protection Class: IP23S
• Minimum Generator (kVA): 13 (Single-Phase) | 23 (Three-Phase)
• Supply Plug: 32A
• Standard: As 60974.1
• Suitable Materials
• MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze
• MMA: Mild Steel, Stainless Steel, Cast Iron
• Imax (A): 32.2 (Single-Phase) | 24.5 (Three-Phase)
• No Load Voltage with VRD Active (V): 9.5
• Insulation Class: H
• Minimum Generator (kVA): 20
• Supply Plug: Unplugged (32A Recommended)
• Ieff (A): 10.0
• Imax (A): 17.6
• Standard: AS 60974.1
• TIG Specifications:
• TIG Duty Cycle @ 40°C: 30% @ 330A, 60% @ 223A, 100% @ 181A
• TIG: Mild Steel, Stainless Steel, Aluminium, Copper, Silicon Bronze, Titanium, Magnesium, Zinc Alloys
• TIG Current Range: 10-330A
• TIG Welding Thickness Range: 1-16mm
• TIG Ignition Type:
• AC/DC High-Frequency
• AC/DC Lift Arc
• MMA Specifications
• MMA Duty Cycle @ 40°C: 30% @ 270A, 60% @ 190A, 100% @ 148A
• MMA: Mild Steel, Stainless Steel, Cast Iron
• MMA Current Range: 10-270A
• MMA Welding Thickness Range: 2-16mm
• MMA Electrode Range: 2.5-4.0mm
• Dimensions (mm): 568x230x416mm
• Weight (kg): 23.8
• Package Dimensions (cm): 682x332x562
• Package Weight (kg): 36.5
• Suitable Materials
• TIG: Mild Steel, Stainless Steel, Aluminium, Copper, Silicon Bronze, Titanium, Magnesium, Zinc Alloys
• MMA: Mild Steel, Stainless Steel, Cast Iron
• Warranty: 5 Years

Features:

• Get incredible results from start to finish with this professional-grade TIG welder, designed for high-end fabrication, and marine and industrial engineering situations. Effortlessly weld any metal with the high-frequency AC/DC TIG.
• HD Backlit Interface: This next generation interface panel is bright and easy to read in any environment.
• Ultimate TIG Welding: Weld every kind of metal. With the ability to run on an Alternating Current (AC) you’re able to weld aluminium as effortlessly as mild and stainless steels on a Direct Current (DC).
• Multiple AC Waveforms: Completely customise your aluminium welds. Switch between Sine, Square, and Triangle waves to change the arc characteristics, bead profile, and penetration to suit your weld.
• Mixed AC/DC: Experience the best of both worlds. Mixed AC/DC combines the efficiency of AC and the penetration of DC- TIG in one weld. With it, you get faster welding speeds, better penetration, a faster weld puddle on cold workpieces, and you can weld on thicker materials.
• Foot Pedal Ready: Enjoy greater control and precision with our optional foot control accessory. This handy feature allows you to easily adjust your TIG amperage on the fly, without interrupting your torch movement. Wireless and wired options available.
• Inverter Technology: Not every inverter is made equal. With UNIMIG’s ever-evolving, state-of-the-art IGBT Inverter technology, you get better performance, better efficiency, and better reliability.
• Smart Fan: Smart Fan diminishes noise, saves power, helps reduce energy costs, and minimises the number of contaminants being pulled through the machine.
• IP23S: Rated IP23S, so it’s protected from touch by fingers and objects greater than 12mm, and water spray less than 60° from vertical while still.
• Advanced MMA Features: Advanced MMA features are designed for improving weld quality and ease of use.
• Job Memory: The job memory function allows you to enter and store weld parameter settings. Weld parameters can be further adjusted and stored as required. A total of 40 jobs can be memorised and stored for recall.
