• Brand: UNIMIG
• Part Number: U11218
• Barcode: 9333521064024
• Replaces: KUMJR350K-SG
• Primary Input Voltage: 415V Three-Phase
• Supply Plug: Unplugged (32A Recommended)
• Ieff (A): 12.6
• Imax (A): 21.4
• Open Circuit Voltage: 80
• Open Circuit Voltage with VRD Active (V): 13.5
• Protection Class: IP23S
• Insulation Class: H
• Minimum Generator (kVA): 20.0
• Dinse Connector: 35/50
• Standard: AS 60974.1
• Warranty: 5 Years
• Weight (kg): 45.10
• Dimensions (LxWxH): 977 x 480 x 753mm
• Suitable Materials :
• MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze
• MMA: Mild Steel, Stainless Steel, Cast Iron
• TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze
• MIG Specifications
• MIG Current Range: 30-350A
• MIG Duty Cycle @ 40°C :
  40% @ 350A
  60% @ 285A
  100% @ 221A
• MIG Wire Sizes: 0.6-1.2mm
• MIG Wire Spool Sizes: 5kg (D200), 15kg (D300)
• MIG Welding Thickness Range: 1-16mm
• Drive Roller Size: 37/24
• TIG Specifications
• TIG Welding:
• TIG Ignition Type: DC Lift Arc
• TIG Current Range: 20-350A
• TIG Duty Cycle @ 40°C :
  40% @ 350A
  60% @ 285A
  100% @ 221A
• TIG Welding Thickness Range: 1-10mm
• MMA Specifications
• MMA Current Range: 20-350A
• MMA Duty Cycle @ 40°C :
  40% @ 350A
  60% @ 285A
  100% @ 221A
• MMA Electrode Range: 2.5-4.0mm
• MMA Welding Thickness Range: 2-16mm

Features:

• Get the job done quickly and efficiently with our versatile three-in-one welding machine. With the ability to perform MIG, TIG and STICK welding all in one unit, you can save valuable time and effort without sacrificing quality.
• Supports both gas-shielded and gasless MIG wire, allowing you to tackle a wide variety of welding projects with ease.
• Whether you’re working with mild steel, stainless steel, aluminium, or flux-cored wire, ourmachine has got you covered.
• With Trigger Controlled DC Lift Arc ignition, starting your welding projects has never been easier. Our Lift Arc TIG technology ensures your tungsten tip won’t stick to the workpiece, preventing costly tip breakages.
• Achieve smooth and steady wire feeding, especially when using softer wires such as aluminium. With a ‘Pull’ motor built into the torch, the wire can be fed over a greater distance, granting you the freedom to move and manoeuvre with ease while MIG welding.
• Make welding aluminium even easier. No need to change your existing setup. The spool gun lets you quickly switch over and get any job done with no downtime.
• The most consistent and smoothest wire-feeding experience there is. With a four geared wire drive unit, there’s more power pushing the wire, improving the wire feeding, especially in longer torches.
• The RAZOR SWF 350 features adjustable Arc Force and Anti-Stick functionality. These features are designed for improving weld quality and ease of use.
  Generator Compatible: Minimum 20kVA recommended.
• Fits both D200 and D300 wire spools, so you can put 15kg mild steel or 7kg aluminium spools in the machine.
• Our digital MIG torch allows you to adjust your settings on the fly.
• No more hassle of constantly adjusting your settings on a separate control panel.
• With our leading technology, you can easily fine-tune the amps, current and voltage at the touch of a torch button.
